DeLonghi DTR 906-DF Series - Injector Selection and Air Vent Tables; Injector Selection Table; Air Vent Requirements for Combustion

2121
LUBRICATION OF THE GAS TAPS
• In case of di󰀩culty in the gas taps operation, call Service.
IMPORTANT
All intervention regarding installation maintenance of the appliance must be fullled
with original factory parts.
The manufacturer declines any liability resulting from the non-compliance of this
obligation.
BURNERS
Nominal
power
[kW]
Reduced
power
[kW]
LPG
G30 28-30
mbar
G31 37 mbar
Natural Gas
G20 20 mbar
Ø
injector
[1/100 mm]
Ø
injector
[1/100 mm]
Auxiliary (A) 1,00 0,40 50 72 (X)
Semi-rapid (SR) 1,75 0,45 65 97 (Z)
Rapid (R) 3,00 0,75 85 128 (H3)
Double-ring compact (DCC) 4,00 1,50 100 150 (H3)
AIR VENT NECESSARY FOR GAS COMBUSTION = (2 m
3
/h x kW)
BURNERS Air necessary for combustion [m
3
/h]
Auxiliary (A) 2,00
Semi-rapid (SR) 3,50
Rapid (R) 6,00
Double-ring compact (DCC) 8,00
TABLE FOR THE CHOICE OF THE INJECTORS
GB
IE
Cat: II 2H3+
