6
134
Ø 5,25 in
3
inthewooden
icboardofaFrench
windoworpanel
inthewall:
youare
recommendedtoinsulate
thesectionofwallusing
suitableinsulation
• FitthewallangeB1intothehole.
• FitthehoseB2intothewallangeB1asshowning.4.
• WhenthehoseB2isnotconnected,thedrilledholecanbe
closedwiththeangecapB1.
4
max 39 in
max 100 cm
min 14 in
min 35 cm
• Wheninstallingtheairconditioner,youshouldleaveadoor
slightlyopenlittleas1/2“(1cm)toguaranteecorrect
ventilationandroompressure.
• Keeptheairhosesasshortandfreeofcurvesaspossibleto
avoidconstrictions.
Note:
• As special tools are required for this type of
installation, we suggest you have the appliance in-
stalled by specialized personnel.
AIR CONDITIONING WITHOUT INSTALLATION
You can also set-up in a double-hung window:
• Placethewindowbracetinthewindowsill,extendthe
bracetfullywithinthewindowframe,xthebracetby
using the pin then lower the window ontothe bracet.
(Shouldthewindowbracetbetoolargeforthewindow,
the plasticcan becut with a saw by a qualied profes-
sional.)
• FittheairexhausthoseB2intherelevanthousinglocated
ontherearsideoftheappliance.(g.1).
• ConnectthewindowoutletB3totheotherendoftheex-
hausthose.
• InsertthewindowoutletB3 oftheexhausthoseintothe
slotofthewindowbracet(g.5).
5
Other set-up methods:
• Thanstothelocingpins,it’spossibletousethewindow
bracetalsoforslidingwindows.Positiontheholeofthe
bracetsotoallowacorrectinstallationoftheexhausthose
(seegure6).
6
