Access Door Module ADM-2W704 (Rev 1.3) Installation & Application Guide
Page 2 of 26 Access Door Module
MODEL NUMBERS
Features ADM-2W704
Controller & Enclosure

UL AUTHORIZED ACCESSORIES
• AWID, Sentinel-Prox SR-2400 4 to 5.5 inch Read Range, Metal Compensated, Indoor
O
THER
A
CCESSORIES FOR USE IN NON
-UL
APPLICATIONS
• R10 - 6100 HID iClass Mullion Indoor/Outdoor Smart Card Reader up to 3½”
• R30 - 6110 HID iClass European/Asian Indoor/Outdoor Smart Card Reader up to 4”
• R40 - 6120 HID iClass Single Gang Indoor/Outdoor Smart Card Reader up to 4¼”
• 200X iClass Card HID Smart Card for Direct Image & Thermal Transfer
• 206X iClass Tag HID Smart Card as Tag with Adhesive Back
• 205X iClass Key HID Smart Card in molded plastic key fob
• Sentinel-Prox HP-6840 6 to 8 inch Read Range, Single Gang Box Mount
• Sentinel-Prox SR-2400 4 to 5.5 inch Read Range, Metal Compensated, Indoor/Outdoor
• Sentinel-Prox MM-6800 6 to 8 inch Read Range, Metal Compensated, Indoor/Outdoor
• Sentinel-Prox SP-6820 6 to 8 inch Read Range, Single Gang Box Mount
• Sentinel-Prox MR-1824 18 to 24 inch Read Range, Dimensions Only 8”x 8” x 1”, Indoor/Outdoor
• Sentinel-Prox MR-1824 MC Metal Compensated Version
• Prox-Line – GR Graphics Quality, both sides, ISO Compliant
• Prox-Line – CS “Clam Shell” style Prox Badge, Pre-Punched in Portrait Orientation
• Prox-Line – KT Proximity Key Tag (Key Fob)
P
ACKAGE
C
ONTENTS
• Access Door Module Board, ADM-2W704 (Rev 1.3)
• Stylized Enclosure for quick mounting
• Access Door Module ADM-2W704 (Rev 1.3) Installation & Application Guide
• Package containing 8-10K Resistors for EOL resistors and 1 pre-wired Battery Connector
R
EQUIRED
T
OOLS
• Terminal flat head screwdriver
• Wire cutters and strippers
• Screws and screw driver for mounting controller
