Delta Controls
Access Door Module Page 3 of 26
OTHER RELEVANT DOCUMENTS
• Access Control System Technical Reference Manual
• Access Control System V3.30 Release Notes
• RS-485 Network Installation Guide (DOC818-11)
• ORCAview Operator Guide
• V3.30 ORCAview Technical Reference Manual
• V3.30 Release Notes
• Delta Controls System Description
RODUCT
PECIFICATIONS
Power Requirements
• 24 VAC, 50/60Hz, 75 VA (dedicated transformer) Class 2 Device
• 4A Slow Blow Fuse for controller and device power
• 7.0 AH Lead Acid Battery Connection (for battery charging and battery back-up of the controller, as
well as all devices connected and powered from the controller)
• DC Power out +14 VDC @ 0.25A with a resetable fuse (can supply one Access System Manager
with battery backup)
• Card reader power +5 VDC @ 50mA or +12 VDC @ 160mA for each card reader individually fused
with a resetable fuse
• Door Lock power +12 VDC @ 350mA for each lock individually fused with a resetable fuse
• Auxiliary DC Power out +12 VDC @ 50mA fused with a resetable fuse
Ambient Ratings
• 32º to 131º F (0º to 55º C)
• 10 to 90% RH (non-condensing)
Communication Ports
NET1 - Main LAN (LINKnet)
• Communications Speed @ 76,800 BPS
• Maximum one Access Door Modules per Access System Manager (ASM)
• Visual LED status of network activity
