Access Door Module ADM-2W704 (Rev 1.3) Installation & Application Guide
Page 4 of 26 Access Door Module
Inputs
• 2 Wiegand Devices
• 5 Type 1,2,3,4 EOL Supervised Inputs
o 2 Door Contacts
o 2 Auxiliary Inputs (i.e. tamper from card reader, motion detector, etc)
o 1 Tamper Input for cabinet
• 2 Request to Exit Inputs (internally wired to door strike output to reduce field wiring)
• 9 Internal Inputs for controller status
o 2 Door Strike/Magnetic Lock Power Status
o 1 Auxiliary Power Status
o 1 AC Power Status
o 1 Battery Status
o 2 Door +5 VDC Power Status
o 2 Door +12 VDC Power Status
Outputs
• 2 Door Locks, Form C Relay (rated 24VDC/AC @ 5A) with MOV protection, internally supplied
with +12 VDC as above.
• 2 Auxiliary Relays, Form C Relay 24VDC/AC @ 5A with MOV protection (N.O. and N.C. contacts
available)
• 4 LED Outputs for control of LEDs on Card readers. Open-collector current sink maximum 24VDC
@50mA current limited (LED or Buzzer output)
Technology
• 8 bit Processor c/w internal A/D, Flash, and RAM
Device Addressing
• Set via DIP switch for LINKnet Address (0 to 12 per LINKnet segment)
Size
Controller & Enclosure
• 8” x 9.5” x 2.5” (20.3 cm x 24.1 cm x 6.4 cm)
Weight (c/w Enclosure)
• Controller & Enclosure = 1.2 lb. (547 g.)
