Chapter 3 Element Function|ScrEdit Software User Manual
Revision Apr. 30th, 2007, 2007PDD23000002 3-37
Property Description of Moving Sign Element
Text / Text Size
Font / Text Color
The user can set the text, text size, font and text color provided by Windows® to
determine the text display on the element. (Please refer to Table 3.2.2 Property
Description of General Buttons.)
Border Color
Background Color
(Please refer to Table 3.8.2 Property Description of Numeric Display Element.)
Style (Please refer to Table 3.8.2 Property Description of Numeric Display Element.)
Bit It can have two states.
Word It can have 256 states.
Data Type
LSB It can have 16 states.
Data Format It provides BCD, Signed Decimal, Unsigned Decimal and Hex four kinds of data
format to define the read memory content.
Add/Remove State It is used to set the state numbers of moving sign element. If the data length of the
value is in Word, 1~256 states can be set. If the data length of the value is in LSB, 16
states can be set. If the data length of the value is in Bit, only 2 states can be set.
Left The display progressing direction is from right to the left.
Right The display progressing direction is from left to the right.
Top The display progressing direction is from bottom to the top.
Direction
Bottom The display progressing direction is from top to the bottom.
Moving Points It is used to set the movement of the moving sign. The unit is Pixel and the range is
within 1 ~ 50 Pixels.
Interval(ms) It is used to set the interval time between two movements. The unit is ms and the
range is within 50 ~ 3000 ms.
