Chapter 2 Creating and Editing Screens|ScrEdit Software User Manual
2-68 Revision Apr. 30th, 2007, 2007PDD23000002
Fig. 2.8.11 Recipe Setup dialog box
Table 2.8.2 Recipe Editing
Recipe Setup
Enable Recipe When the check box next to “Enable Recipe” is checked, the recipe function is
enabled. If the user does not enable this function, the user can not do this function
even the user has downloaded recipe data.
A
ddress The user can input the starting address of recipe data here. It can accept the
address in PLC input format and internal memory format. The user also can click
button to get the address input dialog box (Fig. 2.8.12) to input the starting
address.
Fig. 2.8.12 Input starting address dialog box
