Chapter 7 Servo Parameters|ASDA-A&A+ Series
7-32
Revision April 2009
P1 - 11
SP3 3rd Speed Command or Limit Communication Addr.: 010BH
Default: 300 Related Section:
Applicable Control Mode: S, T Section 6.3.1
Unit: r/min
Range: -5000 ~ +5000
Settings:
3rd Speed Command
In Speed mode, this parameter is used to set speed 3 of internal speed command. For the
decimal place setting of internal speed command, please refer to P2-63.
3rd Speed Limit
In Torque mode, this parameter is used to set speed limit 3 of internal speed command.
P1 - 12
TQ1 1st Torque Command or Limit Communication Addr.: 010CH
Default: 100 Related Section:
Applicable Control Mode: T, P/S Section 6.4.1
Unit: %
Range: -300 ~ +300
Settings:
1st Torque Command
In Torque mode, this parameter is used to set torque 1 of internal torque command.
1st Torque Limit
In Position and Speed mode, this parameter is used to set torque limit 1 of internal torque
command.
Digital output signal TQL is activated when the drive has detected that the motor has reached
the torques limits set by either the parameters P1-12 ~ P1-14 of via an external analog voltage.
P1 - 13
TQ2 2nd Torque Command or Limit Communication Addr.: 010DH
Default: 100 Related Section:
Applicable Control Mode: T, P/S Section 6.4.1
Unit: %
Range: -300 ~ +300
Settings:
2nd Torque Command
In Torque mode, this parameter is used to set torque 2 of internal torque command.
