Chapter 7 Servo Parameters|ASDA-A&A+ Series
7-34
Revision April 2009
P1 - 17 PO2H 2nd Position Command for Rotation Communication Addr.: 0111H
Default: 0 Related Section:
Applicable Control Mode: Pr Section 6.2.2
Unit: rev
Range: -30000 ~ +30000
Settings:
This parameter is used to set rotation cycle number of internal position 2.
P1 - 18 PO2L 2nd Position Command for Pulse Communication Addr.: 0112H
Default: 0 Related Section:
Applicable Control Mode: Pr Section 6.2.2
Unit: pulse
Range: +/-max. cnt/rev
Settings:
This parameter is used to set rotation pulse number of internal position 2.
Stroke2 = PO2H × (cnt/rev) + PO2L
P1 - 19 PO3H 3rd Position Command for Rotation Communication Addr.: 0113H
Default: 0 Related Section:
Applicable Control Mode: Pr Section 6.2.2
Unit: rev
Range: -30000 ~ +30000
Settings:
This parameter is used to set rotation cycle number of internal position 3.
P1 - 20 PO3L 3rd Position Command for Pulse Communication Addr.: 0114H
Default: 0 Related Section:
Applicable Control Mode: Pr Section 6.2.2
Unit: pulse
Range: +/-max. cnt/rev
Settings:
This parameter is used to set rotation pulse number of internal position 3.
Stroke3 = PO3H × (cnt/rev) + PO3L
