Chapter 3 Connections and Wiring|ASDA-A&A+ Series
Revision April 2009 3-31
C4-1: Pulse input (Line driver)
C4-2: High-speed pulse input (Line driver)
¾ Caution: Ensure that the ground terminal of the controller and the servo drive should be connected to each
other.
Because this
photocoupler is a
unidirectional
optocoupler, please pay
close attention on the
current direction of input
pulse command.
