Chapter 8 Servo Parameters
Revision January 2011 8-3
Monitor Parameters
Control
Mode
Parameter Name Function Default Unit
PT
PR
S
T
P0-35 MAP1A
Block Data Read / Write Register 1
(for P0-
25)
0x0 N/A
P0-36 MAP2A
Block Data Read / Write Register 2
(for P0-
26)
0x0 N/A
P0-37 MAP3A
Block Data Read / Write Register 3
(for P0-
27)
0x0 N/A
P0-38 MAP4A
Block Data Read / Write Register 4
(for P0-
28)
0x0 N/A
P0-39 MAP5A
Block Data Read / Write Register 5
(for P0-
29)
0x0 N/A
P0-40 MAP6A
Block Data Read / Write Register 6
(for P0-
30)
0x0 N/A
P0-41 MAP7A
Block Data Read / Write Register 7
(for P0-
31)
0x0 N/A
P0-42 MAP8A
Block Data Read / Write Register 8
(for P0-
32)
0x0 N/A
P0-43 Reserved (Do Not Use)
P0-44 PCMN
Status Monitor Register (PC
Softw
are Setting)
0x0 N/A
P0-45 PCMNA
Status Monitor Register Selection
(PC Soft
ware Setting)
0x0 N/A
P0-46★
SVSTS
Servo Output Status Display
0 N/A
Explanation of symbols (marked after parameter)
(
★) Read-only register.
(
▲) Parameter cannot be set when Servo On (when the servo drive is enabled).
(
) Parameter is effective only after the servo drive is restarted (after switching power off
and on).
(
) Parameter setting values are not retained when power is off.
