GETTING TO KNOW YOUR COFFEE MACHINE
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
On/O General button
Equipment body
Handle
Control panel
Water tank
Adapter for mineral water plastic bottles
Water tank cover
Capsule holder housing
Capsule holder housing opening lever
Capsule collection tank
Cup tray
Drip basin
Extraction nozzle
Electrical plug
Electrical cable
Fig. 1: Qosy automatic.
1
2
5
7
10
8
14
15
9
11
12
13
4
6
3
