15
USING AUXILIARY WOOD FENCE
Fig. 35
When mortising extra high workpieces (A) Fig. 35, an
auxiliary fence (B) can be fastened to the fence (C) with
wood screws (D) through the two holes in the fence. This
provides additional support for the workpiece during the
mortising operation. Note that the holddown (E) can be
turned upside down to accommodate the extra height of
the workpiece.
ROTATING COLUMN 180 DEGREES
The column (A) Fig. 36, can be rotated 180 degrees, as shown, if it is desired to use workpieces off the table. To rotate
the column, remove three screws, two of which are shown at (B), rotate column (A) 180 degrees and replace the three
screws (B).
Fig. 36
B
C
D
E
A
A
B
