4
UNPACKING AND CLEANING
Carefully unpack the tool and all loose items from the carton. Remove the protective coating from all unpainted parts.
This coating may be removed with a soft cloth moistened with kerosene (do not use acetone, gasoline, or lacquer thin-
ner for this purpose).
WARNING: FOR YOUR OWN SAFETY, DO NOT CONNECT THE GRINDER TO THE POWER SOURCE UNTIL
THE MACHINE IS COMPLETELY ASSEMBLED AND YOU HAVE READ AND UNDERSTAND THE ENTIRE
INSTRUCTION MANUAL.
Fig.1
1. Grinder and lamp
2. Eye shield frame (2)
3. Eye shields (2)
4. Rods for eye shields (2)
5. Spark guards (2)
6. Tool rest arms (2)
7. Tool rests (2)
1
2
3
4
5
6
7
