Chapter 8 Parameters ASDA-A2
8-132 Revision February, 2017
Format：
Hexadecimal
Settings：(This function is available in firmware version V1.038 sub26 and later
models)
Format＝UZYX. The functions are listed below.
X: E-CAM Alignment Control
Bit Bit 3 Bit 2 Bit 1 Bit 0
Function Reserved Phase Alignment
Category
Trigger PR
immediately
Enable
Alignment
Description - Set 0 to disable the
function.
Set 1 to enable the
function.
This function is
applicable to film
delivery control of
reverse flying
shear.
Set 1 to enable. When
the alignment DI is
triggered, the
correcting error will be
calculated and stored
in PR specified by P2-
73. If this bit is set to
1, trigger the PR
immediately after DI
activated, otherwise
the user should trigger
the PR manually or
use P5-88.BA to call
the PR when E-Cam
disengaged.
Set 0 to disable.
Set 1 to enable.
If enable, the E-
CAM alignment
correction will
be executed
when DI.ALGN
ON.
Y: Filter intensity
Y 0 1 ~ F
Function Disabled Average of 2^Z: Enabled
When the value of Y is increased, the change of correction is getting
slow and it can expedite the performance of the filter function. This can
avoid the disturbance caused by a sensor noise and a big error to be
corrected within one time. Setting P2-76 too big will cause the
alignment not able to work properly. The recommendatory value is 3.
UZ: Alignment path definition. Forward direction as setting reference
here (0 ~ 100%)
0: Backward alignment only
30: Forward 30%, Backward 70%
50: Alignment with the shortest distance
80: Forward 80%, Backward 20%
>=100: Forward alignment only
P2-77■ CMSK E-Cam Master Axis – Pulse Masking Setting
Address: 029AH
029BH
Operational
Interface：
Panel / Software Communication
Related Section: N/A
Default：
0000h
Control
Mode：
PR
