2 3
PACKAGE CONTENTS
A
1
B
3
5
6
2
4
PART DESCRIPTION QTY
1
Fan Body 1
2
Grille 1
3
Suspension Bracket I 1
4
Suspension Bracket II 1
5
Suspension Bracket III 1
5
Duct Connector 1
HARDWARE CONTENTS
(Images are to scale)
× 8
Long Wood Screw ( ø 4 x 25mm)
× 3
Short Machine Screw (M4 x 12mm)
