Delta DPM-C530A - Page 30

29
C1
pickup setpoint (current THD
exceeding this value, alarm
generated)
0.000~99999.999 Float % 4 R / W
C2
C3
pickup time delay (triggering
delayed)
0~99 byte s 2 R / W
C4
dropout setpoint (current THD
lower than this value (kW), alarm
cleared)
0.000~99999.999 Float % 4 R / W
C5
C6
dropout time delay (restoration
delayed)
0~99 byte s 2 R / W
Alarm - Phase Loss
C7 Alarm Enable
0: Disable
1: Enable
byte 1 R / W
C8
pickup setpoint (phase lower than
this value, alarm generated)
0.000~99999.999 Float V 4 R / W
C9
CA
pickup time delay (triggering
delayed)
0~99 byte s 2 R / W
CB
dropout setpoint (phase
exceeding this value, alarm
cleared)
0.000~99999.999 Float V 4 R / W
CC
CD
dropout time delay (restoration
delayed)
0~99 byte s 2 R / W
Alarm - Over DUI
CE Alarm Enable
0: Disable
1: Enable
byte 1 R / W
CF
pickup setpoint (DUI exceeding
this value, alarm generated)
0.000~99999.999 Float kW 4 R / W
D0
D1
pickup time delay (triggering
delayed)
0~99 byte s 2 R / W
D2
dropout setpoint (DUI lower than
this value, alarm cleared)
0.000~99999.999 Float kW 4 R / W
D3
D4
dropout time delay (restoration
delayed)
0~99 byte s 2 R / W
Alarm - Over EUI
D5 Alarm Enable
0: Disable
1: Enable
byte 1 R / W
D6
pickup setpoint (EUI exceeding
this value, alarm generated)
0.000~99999.999 Float kWh 4 R / W
D7
D8
pickup time delay (triggering
delayed)
0~99 byte s 2 R / W
D9
dropout setpoint (EUI lower than
this value, alarm cleared)
0.000~99999.999 Float kWh 4 R / W
DA
DB
dropout time delay (restoration
delayed)
0~99 byte s 2 R / W
Alarm - Meter Reset
DC Alarm Enable
0: Disable
1: Enable
byte 1 R / W
Alarm - Phase Rotation
DD Alarm Enable
0: Disable
1: Enable
byte 1 R / W
