11
INA INB
Content Explanation CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
1: ON-OFF
2: manual
3: PID programmable
(H1117) (H1217) (H1317) (H1417) (H1517) (H1617) (H1717) (H1817)
Alarm 1 output
mode
See “Alarm Output” section
H10C0
(H1118)
H10C1
(H1218)
H10C2
(H1318)
H10C3
(H1418)
H10C4
(H1518)
H10C5
(H1618)
H10C6
(H1718)
H10C7
(H1818)
Alarm 2 output
mode
See “Alarm Output” section
H10C4
(H1518)
H10C5
(H1618)
H10C6
(H1718)
H10C7
(H1818)
Heating/cooling
cycle for output 1
1 ~ 99 seconds
0 = 0.5 second
H10C8
(H1119)
H10C9
(H1219)
H10CA
(H1319)
H10CB
(H1419)
H10CC
(H1519)
H10CD
(H1619)
H10CE
(H1719)
H10CF
(H1819)
Heating/cooling
cycle for output 2
1 ~ 99 seconds
0 = 0.5 second
H10D0
(H111A)
H10D1
(H121A)
H10D2
(H131A)
H10D3
(H141A)
H10D4
(H151A)
H10D5
(H161A)
H10D6
(H171A)
H10D7
(H181A)
Run/Stop the control
0: stop
1: executing
2: program stops
3: program pauses
H10D8
(H111B)
H10D9
(H121B)
H10DA
(H131B)
H10DB
(H141B)
H10DC
(H151B)
H10DD
(H161B)
H10DE
(H171B)
H10DF
(H181B)
Status of PID auto-
tuning
0: stop
1: executing
H10E0
(H111C)
H10E1
(H121C)
H10E2
(H131C)
H10E3
(H141C)
H10E4
(H151C)
H10E5
(H161C)
H10E6
(H171C)
H10E7
(H181C)
Positive/negative
proportional output
0: positive
1: negative (slope)
H10E8
(H111D)
H10E9
(H121D)
H10EA
(H131D)
H10EB
(H141D)
H10EC
(H151D)
H10ED
(H161D)
H10EE
(H171D)
H10EF
(H181D)
Other statuses Other statuses
H10F0
Temperature
unit
H10F1
Open special
function
(H1234)
H10F2
Return to
default
(H1357)
H10F3
Reserved
H10F4
Reserved
H10F5
Reserved
H10F6
Channel
disable
H10F7
Filter times
Communication
specifications
See Table 4
H10F8
Auto ID
setup
H10F9
Filter range
H10FA
Baud rate
H10FB
ASCII = 0
RTU = 1
H10FC
8 bits=0
7 bits=1
H10FD
2 stop=0
1 stop=1
H10FE
Parity
H10FF
Address
1 ~ 247
LED Status
b0: none; b1: Alarm; b2: °C; b3:
°F; b4: Alarm 1; b5: OUT2; b6:
OUT1; b7: AT
H1124 H1224 H1324 H1424 H1524 H1624 H1724 H1824
Communication Parameter Setting:
Content
0 1 2 3 4 5 6
Baud rate 2,400bps 4,800bps 9,600bps 19,200bps 38,400bps 57,600bps 115,200bps
Parity bit None (N) Even (E) Odd (O)
Table 4
Error Codes:
The error codes can be read from address H1000 ~ H1007. When the input operation is in normal status, H1000 ~ H1007 are for input
values. When input error occurs (except for stable status and input exceeding the range), DTE will read error codes in H8001 ~ H8002.
H1000 Error description
H8001 EEPROM cannot be written in.
H8002 Input sensor is not connected.
H8003 Group INB is not connected.
Table 5
Analog output current tuning scale: 1μA/scale
Analog output voltage tuning scale: 1mV/scale
Returning to Default Value: Write H1234 into address H10F1 and H1357 into address H10F2. Restart DTE.
Programmable Communication Parameter Setting:
INA INB
Content Explanation CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
Read remaining time of the step Unit: sec H111E H121E H131E H141E H151E H161E H171E H181E
Read remaining time of the step Unit: min H111F H121F H131F H141F H151F H161F H171F H181F
Read the NO. of the current pattern 0 ~ 7 H1120 H1220 H1320 H1420 H1520 H1620 H1720 H1820
