Delta DTE10T Series User Manual

12
INA INB
Content Explanation CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
Read the NO. of the current step 0 ~ 7 H1121 H1221 H1321 H1421 H1521 H1621 H1721 H1821
NO. of start pattern 0 ~ 7 H1122 H1222 H1322 H1422 H1522 H1622 H1722 H1822
NO. of start step 0 ~ 7 H1123 H1223 H1323 H1423 H1523 H1623 H1723 H1823
Programmable Parameter Setting:
Content Explanation Pattern 0 Pattern 1 Pattern 2 Pattern 3 Pattern 4 Pattern 5 Pattern 6 Pattern 7
Max. number of steps
in the pattern
0 ~ 7 = N: The pattern
executes from step 0 to N.
H2068 H2069 H206A H206B H206C H206D H206E H206F
Number of cycles of
pattern 0 ~ 7 execution
0 ~ 199: The pattern has
been executed for 1 ~ 200
times
H2070 H2071 H2072 H2073 H2074 H2075 H2076 H2077
NO. of current link
pattern
0 ~ 8: 8 refers to end of
program; 0 ~ 7 refer to the
NO. of next pattern
H2078 H2079 H207A H207B H207C H207D H207E H207F
Address Default Content Explanation
2000H ~ 203FH 0
Target temperatures for pattern 0 ~ 7
Pattern 0: 2000H ~ 2007H
Unit: 0.1°C
2080H ~ 20BFH 0
Execution time for pattern 0 ~ 7
Pattern 0: 2080H ~ 2087H
Time: 0 ~ 900 (Unit: 1 min)
4. Communication format: H03 = read bit data; H06 = write bit data
ASCII Mode:
 Single read and write:
Read Command Read Response Message Write Command Write Response Message
Start word ’:’ Start word ’:’ Start word ’:’ Start word ’:’
Machine address 1 ‘0’ Machine address 1 ‘0’ Machine address 1 ‘0’ Machine address 1 ‘0’
Machine address 0 ‘1’ Machine address 0 ‘1’ Machine address 0 ‘1’ Machine address 0 ‘1’
Command 1 ‘0’ Command 1 ‘0’ Command 1 ‘0’ Command 1 ‘0’
Command 0 ‘3’ Command 0 ‘3’ Command 0 ‘6’ Command 0 ‘6’
Read start address of
data/bit
‘1’
Length of response data
(byte)
‘0’
Data address
‘1’
Data address
‘1’
‘0’ ‘4’ ‘0’ ‘0’
‘0’
Data content in H1000
‘0’ ‘0’ ‘0’
‘0’ ‘1’ ‘1’ ‘1’
Read length of data/bit
(word/bit)
‘0’ ‘F’
Write data content
‘0’
Write data content
‘0’
‘0’ ‘4’ ‘3’ ‘3’
‘0’
Data content in H1001
‘0’ ‘E’ ‘E’
‘2’ ‘0’ ‘8’ ‘8’
LRC1 check ‘E’ ‘0’ LRC1 check ‘F’ LRC1 check ‘F’
LRC0 check ‘A’ ‘0’ LRC0 check ‘D’ LRC0 check ‘D’
End word 1 CR LRC1 check ‘0’ End word 1 CR End word 1 CR
End word 0 LF LRC0 check ‘3’ End word 0 LF End word 0 LF
End word 1 CR
End word 0 LF
 Multi write: maximum 32 words
Multi Write Command Multi Write Response Command
Start word ’:’ Start word ’:’
Machine address 1 ‘0’ Machine address 1 ‘0’
Machine address 0 ‘1’ Machine address 0 ‘1’
Command 1 ‘1’ Command 1 ‘1’
Command 0 ‘0’ Command 0 ‘0’
Data address
‘1’
Data address
‘1’
‘0’ ‘0’
