DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
2-66
Device
Function
If D1062 is ON, the average value is the current value.
Displaying the status of the analog input channel of 30EX2
Please see the explanation below for more information.
D1114
Enable/disable 20EX2/SX2 AD channels
(0: enable (default) / 1: disable)
bit0~bit3 sets AD0~AD3.
30EX2 does not support this function.
D1116
Output value of analog output channel 0 (DA 0) of EX2/SX2
D1117
Output value of analog output channel 1 (DA 1) of 20EX2/SX2
30EX2 does not support this function.
D1118
For EX2/SX2 series, sampling time of analog/digital conversion. Sampling
time will be regarded as 2ms If D1118
≦
2.
The description of D1113 for 30EX2:
Bit15~12
Bit11~8
Bit7~4
Bit3~0
Reserved
Status of the analog
input channel (AD2)
Status of the analog
input channel (AD1)
Status of the analog
input channel (AD0)
The status of the analog input channel of 30EX2:
Status
0x0
0x1
0x2
Description Normal
The analog input exceeds the
upper/lower limit.
The temperature sensor is
disconnected.
The upper/lower limit values for the analog input mode of 30EX2:
Analog input mode
Upper limit value
Lower limit value
Voltage
-10~+10 V
+32384 -32384
-5V~+5 V
+1 V~+5 V
+32384
-384
Current
-20 mA~+20 mA
+32384
-32384
+4 mA~+20 mA
+32384
-384
Temperature
PT100/PT1000
+8100
-1900
NI100/NI1000
+1800
-900
Device
number
Function
D1115
20EX2/SX2 analog input/output mode setting (Default=H’0)
bit0~bit5: Selection between the voltage/current mode (0: Voltage; 1: Current;
Default: Voltage)
bit0~bit3: Analog inputs (AD0~AD3)
bit4~bit5: Analog outputs (DA0~DA1)
bit8~bit 13: Current mode
bit8~bit11: AD0~AD3 (0: -20 mA~20 mA; 1: 4~20 mA)
bit12~bit13: DA0~DA1 (0: 0~20 mA; 1: 4~20 mA)
30EX2 analog input/output mode setting (Default=H’FFFF)
The description of D1115 for 30EX2:
Bit15~12
Bit11~8
Bit7~4
Bit3~0
Analog output mode
of DA0
Analog input mode
of AD2
Analog input mode
of AD1
Analog input mode
of AD0
The analog input modes for 30EX2:
Code
0x0
0x1
0x2
0x3
Description Two-wire PT100
Three-wire
NI100
Two-wire
PT1000
Two-wire NI1000
Code
0x4
0x5
0x6
0x7
Description
Three-wire
Three-wire
Three-wire
Three-wire
