3.6.10 Basic Instructions
API
Mnemonic
PULSE Function
Applicable to STEPS
16 bits 32 bits
ES2
EX2
EC5
SS2
SA2
SE
SX2 16-bit 32-bit
89
PLS
-
-
Rising-edge output
   
3
-
90 LDP - -
Rising–edge detection
operation
    3 -
91 LDF - -
Falling–edge detection
operation
    3 -
92 ANDP - - Rising-edge series connection     3 -
93
ANDF
-
-
Falling-edge series connection
   
3
-
94
ORP
-
-
Rising-edge parallel connection
   
3
-
95 ORF - - Falling-edge parallel connection     3 -
96
TMR
-
-
Timer
   
4
-
97
CNT
DCNT
-
Counter
   
4
6
98
INV
-
-
Inverse operation
   
1
-
99
PLF
-
-
Falling-edge output
   
3
-
258
ATMR
-
-
Contact type timer
   
5
-
