Delta DVP-SS2

3. Instruction Set
3-317
API Mnemonic Operands Function
Controllers
ES2/EX2/
EC5
SS2
SA2
SE
SX2
96 TMR Timer
Type
OP
Bit Devices Word devices Program Steps
X Y M S K H KnX KnY KnM KnS T C D E F
TMR: 5 steps
S
1
*
S
2
*
*
PULSE
16-bit
32-bit
ES2/EX2/
EC5
SS2
SA2
SE
SX2
ES2/EX2/
EC5
SS2
SA2
SE
SX2
ES2/EX2/
EC5
SS2
SA2
SE
SX2
Operands:
S
1
: No. of timer (T0~T255) S
2
: Set value (K0~K32,767, D0~D9,999)
Explanations:
When TMR instruction is executed, the specific coil of timer is ON and the timer is enabled. When
the set value of timer is achieved, the associated NO/NC contact will be driven.
Program example:
Ladder Diagram:
X0
T5TMR
K1000
Instruction Code: Operation:
LD X0 ; Load NO contact X0
TMR T5 K1000 ; T5 timer setting is K1000
