3. Instruction Set
API
Mnemonic Operands Function
SS2
SX2
00 CJ P
Conditional Jump
OP Range Program Steps
P0~P255
CJ, CJP: 3 steps
SS2
SX2
SS2
SX2
SS2
SX2
Operands:
S: The destination pointer P of the conditional jump.
Explanations:
1. If users need to skip a particular part of PLC program in order to shorten the scan time and
execute dual outputs, CJ instruction or CJP instruction can be adopted.
2. When the program designated by pointer P is prior to CJ instruction, WDT timeout will occur
and PLC will stop running. Please use it carefully.
3. CJ instruction can designate the same pointer P repeatedly. However, CJ and CALL cannot
designate the same pointer P; otherwise operation error will occur
4. Actions of all devices while conditional jump is being executed:
a) Y, M and S remain their previous status before the conditional jump takes place.
b) 10ms and 100ms timer that is executing stops.
c) Timer T192 ~ T199 that execute the subroutine program will continue and the output
contact executes normally.
d) The high-speed counter that is executing the counting continues counting and the output
contact executes normally.
e) General counters stop executing.
f) If timer is reset before CJ instruction executes, the timer will still be in the reset status
while CJ instruction is being executed.
g) The application instructions that are being executed, i.e. DHSCS, DHSCR, DHSZ, SPD,
PLSY, PWM, PLSR, PLSV, DRVI, DRVA, continue being executed.
