Delta DVP-SS2 User Manual

DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
3-64
API Mnemonic Operands Function
Controllers
ES2/EX2/
EC5
SS2
SA2
SE
SX2
18 D BCD P
Convert BIN to BCD
Type
OP
Bit Devices Word devices Program Steps
X Y M S K H KnX KnY KnM KnS T C D E F
BCD, BCDP: 5 steps
DBCD, DBCDP: 9 steps
S
*
*
*
*
*
*
*
*
*
D
*
*
*
*
*
*
*
*
PULSE
16-bit
32-bit
ES2/EX2
/EC5
SS2
SA2
SE
SX2
ES2/EX2
/EC5
SS2
SA2
SE
SX2
ES2/EX2
/EC5
SS2
SA2
SE
SX2
Operands:
S: Source of data D: Conversion result
Explanations:
1. The content in S (BIN value) is converted into BCD value and stored in D
2. As a 16-bit (32-bit) instruction, when the conversion result exceeds the range of 0 ~ 9,999 (0 ~
99,999,999), and M1067, M1068 = ON, D1067 will record the error code 0E18 (hex)
3. If operand S and D use index register F, only 16-bit instruction is available.
4. Flags: M1067 (Program execution error), M1068 (Execution error locked), D1067 (error code)
Program example:
1. When X0 = ON, the binary value of D10 will be converted into BCD value, and the 1s digit of
the conversion result will be stored in K1Y0 (Y0 ~ Y3, the 4 bit devices).
BCD D10 K1Y0
X0
2. If D10=001E (Hex) = 0030 (decimal), the result will be Y0~Y3 = 0000(BIN).
