DVP-ES2/EX2/SS2/SA2/SX2/SE&TP Operation Manual - Programming
M1000
FLT D10 D100
BIN K2X0 D
200
FLT D200 D202
DEDIV K615 K10
DEDIV D100 D202
DEMUL D400 D300
DEBCD D20 D30
DINT D20 D40
D300
D400
D20
1
2
3
4
5
6
7
8
1. Covert D10 (BIN integer) to D101, D100 (floating point).
2. Covert the value of X7~X0 (BCD value) to D200 (BIN value).
3. Covert D200 (BIN integer) to D203, D202 (floating point).
4. Save the result of K615 ÷ K10 to D301, D300 (floating point).
5. Divide the floating point:
Save the result of (D101, D100) ÷ (D203, D202) to D401, D400 (floating point).
6. Multiply floating point:
Save the result of (D401, D400) × (D301, D300) to D21, D20 (floating point).
7. Covert floating point (D21, D20) to decimal floating point (D31, D30).
8. Covert floating point (D21, D20) to BIN integer (D41, D40).
