3. Pulse output devices for operand D: Y0, Y1, Y2, Y3. For EC5, the available pulse output devices
for operand D are Y0, Y2, Y4 and Y6.
4. When several pulse output instructions (PLSY, PWM, PLSR) use Y1 or Y3 as the output device
in the same scan cycle, PLC will perform the instruction which is executed first.
5. When S
1
≦0, S
2
≦0 or S
1
＞S
2
, errors will occur (M1067 and M1068 will not be ON) and no output
will be generated from pulse output devices. When S
1
= S
2
, the pulse output device will be ON
continuously.
6. S
1
, S
2
can be changed when PWM instruction is being executed. But the output time unit (M
flags) cannot be changed during the execution of PWM instruction. You need to set the output
time unit before the execution of PWM instruction.
7. When M1112 = ON, the unit of Y0 output pulse is 10μs, when M1112 = OFF, the unit is 100μs.
8. When M1070 = ON, the unit of Y1 output pulse is 100μs, when M1070 = OFF, the unit is 1ms.
(Not available for EC5)
9. When M1113 = ON, the unit of Y2 output pulse is 10μs, when M1113 = OFF, the unit is 100μs.
(Not available for DVP-12SE.)
10. When M1113 = ON, the unit of Y2 output pulse is 100μs, when M1113 = OFF, the unit is 1ms. (It
is only applicable to DVP-12SE.)
11. When M1071 = ON, the unit of Y3 output pulse is 100μs, when M1071 = OFF, the unit is 1ms.
(Not available for EC5)
12. For EC5, when M1530 = ON, the unit of Y4 output pulse is 10 μs, when M1530 = OFF, the unit
is 100 μs.
13. For EC5, when M1531 = ON, the unit of Y6 output pulse is 10 μs, when M1531 = OFF, the unit
is 100 μs.
14. When M1116 is ON, M1112 and M1113 do not work. The time unit of the pulse output through
Y0 and Y2 is 1μs. Availabilities are shown below:
15. When M1117 is ON, M1070 and M1071 do not work. The time unit of the pulse output through
Y1 and Y3 is 10μs. Availabilities are shown below:
16. If M1116 for DVP-SS2 is enabled, the minimum pulse output width should be larger than 20.
Otherwise, due to the limitations on the hardware bandwidth of Y0 and Y2, the output result is
not the correct time width.
Model ES2/EX2 ES2-C ES2-E 12SA2 SX2 SS2 12SE 26SE 28SA2
Version
V3.00 V3.20 V1.00 2.60 2.40 2.80 V2.02 V1.0 V2.88
Model ES2/EX2 ES2-C ES2-E 12SA2 SX2 SS2 12SE 26SE 28SA2
Version
V3.00
V3.20
V1.00
2.60
2.40
2.80
V2.02
V1.0
V2.88
