3. Instruction Set
Program Example 2:
1. Use TMR instruction to write in 10 groups of set time.
2. Write the set values into D100 ~ D109 in advance
3. The timer resolution is 0.1 sec for timers T0 ~ T9 and 1 sec for the teaching timer.
4. Connect the 1-bit DIP switch to X0 ~ X3 and use BIN instruction to convert the set value of the
switch into a bin value and store it in E.
5. The ON duration (in sec) of X20 is stored in D200.
6. M0 is a pulse for one scan cycle generated when the teaching timer button X20 is released.
7. Use the set number of the DIP switch as the index pointer and send the content in D200 to
D100E (D100 ~ D109).
M10
TMR T0 D100
M11
TMR T1 D101
M19
TMR T9 D109
M1000
BIN K1X0 E
X20
TTMR D200 K0
X20
PLF M0
M0
MOV D100 D200E
Note:
The TTMR instruction can only be used 8 times in a program. If TTMR is used in a CALL subroutine
or interrupt subroutine, it only can be use once.
