Delta DVP-SS2 User Manual

DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
3-456
API Mnemonic Operands Function
Controllers
ES2/
EX2
SS2
SA2
SX2
SE
178 D SPA
Solar Panel
Positioning
Type
OP
Bit Devices Word devices Program Steps
X Y M S K H KnX KnY KnM KnS T C D E F
DSPA: 9 steps
S
*
*
*
D
*
PULSE
16-bit
32-bit
ES2/
EX2
SS2
SA2
S
X2
SE
ES2/
EX2
SS2
SA2
SX2 SE
ES2/
EX2
SS2
SA2 SX2 SE
Operands:
S: Start device for input parameters D: Start device for output parameters
Explanations:
1. This instruction is a function provided for free. It is for non-commercial use only. If users want to
use the instruction for a commercial purpose, they have to obtain permission from related
organizations before they sell equipment.
2. Operand S occupies 208 consecutive word registers. The function of each device is as below:
No.
Content
Range
Format
Note
S + 0
Year
2000 ~
Word
Please enter the
correct time of the local
longitude. Please refer
to DTM (parameter 11)
for the conversion
formula. A simple
illustration is as in point
6.
S + 1
Month
1 ~ 12
Word
S + 2
Day
1 ~ 31
Word
S + 3
Hour
0 ~ 23
Word
S + 4
Minute
0 ~ 59
Word
S + 5 Second
0 ~ 59
Word
S + 6~7
Time difference (Δt) (sec)
± 8000
Float
S + 8~9
Local time zone
± 12
Float
West: negative
S + 10~11 Longitude ± 180 Float
West: negative
Unit: degree
S + 12~13 Latitude ± 90 Float
South: negative Unit:
degree
S + 14~15 Elevation
0~
6500000
Float Unit: meter
S + 16~17
Pressure
0 ~ 5000
Float
Unit: millibar
S + 18~19
Mean annual temperature (MAT)
-273~6000
Float
Unit: °C
S + 20~21
Slope
± 360
Float
S + 22~23
Azimuth
± 360
Float
S + 24~25
Atmospheric refraction between
sunrise and sunset
± 5
Float
S +26~207
Reserved for system operation
