Delta DVP-SS2 User Manual

2. Programming Concepts
2-27
Special
M
Function
ES2
EX2
EC5
SS2
SA2
SE
SX2
OFF

ON
STOP

RUN
RUN

STOP
Attrib.
Latch
-ed
Default
D1990 and D1991 for the fixed slope of
Y3. (ON: Enable; OFF: Disable) Available
for ES2/EX2: V3.28, ES2-E: V1.00,
12SA2/SX2: V2.82, SS2: V3.24, SE:
V2.00, 28SA2: V2.90.
M1610
Enable pulse output at the maximum
frequency of the ramp up/down set in
D1970 and D1971 for the fixed slope of
CH2 (Y4/Y5). (ON: Enable; OFF: Disable)
EC5
╳ ╳ ╳
OFF OFF - R/W NO OFF
M1611
Enable pulse output at the maximum
frequency of the ramp up/down set in
D1972 and D1973 for the fixed slope of
CH3 (Y6/Y7) (ON: Enable; OFF: Disable)
EC5
╳ ╳ ╳
OFF OFF - R/W NO OFF
M1614 Enabling the drive function
ES2-
C
V3.48
╳ ╳ ╳
OFF - - R/W NO OFF
M1615 Drive initializaiton complete
ES2-
C
V3.48
╳ ╳ ╳
OFF - OFF R/W NO OFF
M1616 Drive error
ES2-
C
V3.48
╳ ╳ ╳
OFF - OFF R/W NO OFF
M1617
Independent heartbeat mode (ON:
independent mode, OFF: linking mode
ES2-
C
V3.49
╳ ╳ ╳
OFF - OFF R/W NO OFF
M1620
Communication protocol for CANRS
instruction; OFF: 2.0B, ON: 2.0A);
available for ES2-C: V3.49, SA2/SX2:
V3.02, 12SE: V1.87, 26SE: V2.02 or later
ES2-
C
╳ ○ ○
OFF - - R/W NO OFF
M1621
Communication mode (Master/Slave) for
CANRS instruction; OFF: master, ON:
slave) ; available for ES2-C: V3.49,
SA2/SX2: V3.02, 12SE: V1.87, 26SE:
V2.02 or later
ES2-
C
╳ ○ ○
OFF - - R/W NO OFF
M1622
Single or two ways communication for
CANRS instruction; OFF: two ways, ON:
single way; available for ES2-C: V3.49,
SA2/SX2: V3.02, 12SE: V1.87, 26SE:
V2.02 or later
ES2-
C
╳ ○ ○
OFF - - R/W NO OFF
M1623
Communication error for CANRS
instruction; available for ES2-C: V3.49,
SA2/SX2: V3.02, 12SE: V1.87, 26SE:
V2.02 or later
ES2-
C
╳ ○ ○
OFF - - R/W NO OFF
M1624
For drive instructions, drive #1 pulse
outputting complete
ES2-
C
V3.48
╳ ╳ ╳
OFF - OFF R/W NO OFF
M1625
For drive instructions, drive #2 pulse
outputting complete
ES2-
C
V3.48
╳ ╳ ╳
OFF - OFF R/W NO OFF
M1626
For drive instructions, drive #3 pulse
outputting complete
ES2-
C
V3.48
╳ ╳ ╳
OFF - OFF R/W NO OFF
M1627
For drive instructions, drive #4 pulse
outputting complete
ES2-
C
V3.48
╳ ╳ ╳
OFF - OFF R/W NO OFF
M1628
For drive instructions, drive #5 pulse
outputting complete
ES2-
C
V3.48
╳ ╳ ╳
OFF - OFF R/W NO OFF
M1629
For drive instructions, drive #6 pulse
outputting complete
ES2-
C
V3.48
╳ ╳ ╳
OFF - OFF R/W NO OFF
M1630
For drive instructions, drive #7 pulse
outputting complete
ES2-
C
V3.48
╳ ╳ ╳
OFF - OFF R/W NO OFF
M1631
For drive instructions, drive #8 pulse
outputting complete
ES2-
C
V3.48
╳ ╳ ╳
OFF - OFF R/W NO OFF
M1632
For drive instructions, drive #1 ramp-
down stop
ES2-
C
V3.48
╳ ╳ ╳
OFF - OFF R/W NO OFF
M1633
For drive instructions, drive #2 ramp-
down stop
ES2-
C
V3.48
╳ ╳ ╳
OFF - OFF R/W NO OFF
M1634
For drive instructions, drive #3 ramp-
down stop
ES2-
C
V3.48
╳ ╳ ╳
OFF - OFF R/W NO OFF
M1635
For drive instructions, drive #4 ramp-
down stop
ES2-
C
V3.48
╳ ╳ ╳
OFF - OFF R/W NO OFF
M1636
For drive instructions, drive #5 ramp-
down stop
ES2-
C
V3.48
╳ ╳ ╳
OFF - OFF R/W NO OFF
