DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
2-32
When X0 = ON, RST instruction resets
C0. Every time When X1 is driven, C0 will
count up (add 1).
When C0 reaches the preset value K5,
output coil Y0 will be ON and C0 will stop
counting and ignore the signals from input
X1.
X0
X1
0
1
2
3
4
5
0
Contacts Y0, C0
C0
present
value
settings
M relays M1200~M1254 are used to set the up/down counting direction for C200~C254
respectively. Setting the corresponding M relay ON will set the counter to count down.
Example:
LD X10
C200
Y0
X12
C200 K-5DCNT
X11
C200RST
X10
M1200
OUT M1200
LD
X11
RST C200
LD X12
CNT C200 K-5
LD C200
OUT Y0
a) X10 drives M1200 to
determine counting direction
(up / down) of C200
b) When X11 goes from OFF to
ON, RST instsruction will be
executed and the PV (present
value) in C200 will be cleared
and contact C200 is OFF.
c) When X12 goes from Off to
On, PV of C200 will count up
(plus 1) or count down (minus
1).
d) When PV in C200 changes
from K-6 to K-5, the contact
C200 will be energized. When
PV in C200 changes from K-5
to K-6, the contact of C200
will be reset.
e) If MOV instruction is applied
through WPLSoft or HPP to
designate a value bigger than
SV to the PV register of C0,
next time when X1 goes from
OFF to ON, the contact C0
will be ON and PV of C0 will
equal SV.
X10
X11
X12
0
1
2
3
4
5
4
3
2
1
0
-1
-2
-3
-4
-5
-6
-7
-8
0
-7
-6
-5
-4
-3
Contacts
Y0, C0
Accumulatively
increasing
Accumulatively
increasing
Progressively
decreasing
PV in
C200
When the output contact
was On.
