3. Instruction Set
3-569
API Mnemonic Operands Function
Controllers
ES2/EX2
SS2
SA2
SE
SX2
270 D BLDI Load NC Contact by Specified Bit
Type
OP
Bit Devices Word devices Program Steps
X Y M S K H KnX KnY KnM KnS T C D E F
BLDI: 5 steps
DBLDI: 9 steps
S
*
*
*
*
*
*
n
*
*
*
*
*
*
*
*
*
*
*
PULSE
16-bit
32-bit
ES2/
EX2
SS2
SA2/
SE
SX2
ES2/
EX2
SS2
SA2/
SE
SX2
ES2/
EX2
SS2
SA2/
SE
SX2
Operands:
S: Reference source device n: Reference bit
Explanations:
1. For ES2/EX2 models, only V1.20 or above supports the function.
2. Available range for the value in operand n: K0~K15 for 16-bit instruction; K0~K31 for 32-bit
instruction.
BLD instruction is used to load NC contact whose contact state is defined by the reference bit n in
reference device D, i.e. if the bit specified by n is ON, the NC contact will be ON, and vice versa.
Program Example:
BLDI D0 K1 Y0
Instruction: Operation:
BLDI D0 K1 Load NC contact with bit
status of bit1 in D0
OUT Y0 Drive coil Y0
