Delta DVP-SS2

2. Programming Concepts
2-41
Special
D
Content
ES2
EX2
EC5
SS2
SA2
SE
SX2
OFF

ON
STOP

RUN
RUN

STOP
Attrib.
Latch
-ed
Default
D1133
Number of pulses for ramp-down operation
of positioning instruction (Low word)
○ ○ ○ ○
0 - - R NO 0
D1134
Number of pulses for ramp-down operation
of positioning instruction (High word)
○ ○ ○ ○
0 - - R NO 0
D1135*
Pulse number for masking Y2 when M1158
= ON (Low word)
ES2/
EX2
○ ○ ○
0 0 - R/W NO 0
D1136*
Pulse number for masking Y2 when M1158
= ON (High word)
ES2/
EX2
○ ○ ○
0 0 - R/W NO 0
D1137*
Address where incorrect use of operand
occurs
○ ○ ○ ○
0 0 - R NO 0
D1140* Number of I/O modules (max. 8)
ES2/
EX2
○ ○ ○
0 - - R NO 0
D1142*
Number of input points (X) on DIO modules
○ ○ ○ ○
0
-
-
R
NO
0
D1143*
Number of output points (Y) on DIO
modules
○ ○ ○ ○
0 - - R NO 0
D1145*
Number of the connected let-side modules
╳ ╳ ○ ○
0
-
-
R
NO
0
D1150*
Vale fetched from the hardware counter
C243/C245/C246/C247/C248/C251/C252
(Low word)
V
3.28
V
3.28
SA2:
V2.82
V2.82
0 - - R/W NO 0
D1151*
Value fetched from the hardware counter
C243/C245/C246/C247/C248/C251/C252
(High word)
V
3.28
V
3.28
SA2:
V2.82
V2.82
0 - - R/W NO 0
D1152*
Value fetched from the hardware counter
C244/C249/C250/C253/C254 (Low word)
V
3.28
V
3.28
SA2:
V2.82
V2.82
0 - - R/W NO 0
D1153*
Value fetched from the hardware conter
C244/C249/C250/C253/C254 (High word)
V
3.28
V
3.28
SA2:
V2.82
V2.82
0 - - R/W NO 0
D1167
The specific end word to be detected for
RS instruction to execute an interruption
request (I140) on COM1 (RS-232).
○ ○ ○ ○
0 - - R/W NO 0
D1168
For RS instruction COM2 (RS-485):
When M1263 is ON, the value in D1168
indicates a specific end word to be seen as
an interrupt request; unit: ms. It is
suggested to set this value shorter than
what the timeout value is set in D1129.
When M1263 is OFF, and the received
data is low-byte of a specific word, the
interrupt (I150) is triggered.
○ ○ ○ ○
0 - - R/W NO 0
D1169
The specific end word to be detected for
RS instruction to execute an interruption
request (I160) on COM3 (RS-485)
ES2/
EX2
╳ ○ ╳
0 - - R/W NO 0
D1175
Number of communication packets
received via broadcasting (number of
slaves) by executing CANRS instruction
ES2-C
╳ ○ ○
0 0 - R NO 0
D1176
Error code for ETHRS instruction
(available for ES2-E: V1.2, 12SE: V1.92,
26SE: V2.00 and later)
ES2-C
╳
SE
╳
0 0 - R NO 0
D1177
Communication timeout setting for CANRS
instruction (available for ES2-C: V3.48,
SA2/SX2: V2.89, SE: V1.83 and later)
ES2-C
╳ ○ ○
200 - - R/W NO 200
D1178
VR0 value
╳ ╳ ○ ○
0
-
-
R
NO
0
D1179
VR1 value
╳ ╳ ○ ○
0
-
-
R
NO
0
D1182
Index register E1
○ ○ ○ ○
0
-
-
R/W
NO
0
D1183
Index register F1
○ ○ ○ ○
0
-
-
R/W
NO
0
D1184
Index register E2
○ ○ ○ ○
0
-
-
R/W
NO
0
D1185
Index register F2
○ ○ ○ ○
0
-
-
R/W
NO
0
D1186
Index register E3
○ ○ ○ ○
0
-
-
R/W
NO
0
D1187
Index register F3
○ ○ ○ ○
0
-
-
R/W
NO
0
D1188
Index register E4
○ ○ ○ ○
0
-
-
R/W
NO
0
D1189
Index register F4
○ ○ ○ ○
0
-
-
R/W
NO
0
D1190
Index register E5
○ ○ ○ ○
0
-
-
R/W
NO
0
D1191
Index register F5
○ ○ ○ ○
0
-
-
R/W
NO
0
D1192
Index register E6
○ ○ ○ ○
0
-
-
R/W
NO
0
D1193
Index register F6
○ ○ ○ ○
0
-
-
R/W
NO
0
D1194
Index register E7
○ ○ ○ ○
0
-
-
R/W
NO
0
D1195
Index register F7
○ ○ ○ ○
0
-
-
R/W
NO
0
