Delta DVP-SS2 User Manual

Appendix C Inforamation about TP Series Text Panels
C-13
 Special devices for TP analog
Device 22XA1R/T 21EX1R/T
D1110
The present value of the analog input
channel 0 (AD0)
The present value of the analog
input channel 0 (AD0)
D1111
The present value of the analog input
channel 1 (AD1)
The present value of the analog
input channel 1 (AD1)
D1112
The present value of the analog input
channel 2 (AD2)
The present value of the temperature
input channel 3 (PT3)
D1113
The present value of the analog input
channel 3 (AD3)
The present value of the temperature
input channel 4 (PT4)
D1114 Mode setting for analog channel of TP04P
D1115
Mode setting for analog channel of TP70P
D1116
The present value of the analog output
channel 4 (DA4)
The present value of the analog
output channel 2 (DA2)
D1117
The present value of the analog output
channel 4 (DA4)
N/A
Note: the temperature input channel only supports Pt100. No setup is needed.
 Device settings for 22XA1R/T
D1114 (TP04P) / D1115 (TP70P)
Bit15-12
Bit11-10
Bit9-8
Bit7-6
Bit5-4
Bit3-2
Bit1-0
N/A
DA5
DA4
AD3
AD2
AD1
AD0
Value
AD mode
DA mode
00 -10V~10V -10V~10V
01 -20mA~+20mA 0mA~20mA
10 4mA~20mA 4mA~20mA
 Device settings for 21EX1R/T
D1114(TP04P) / D1115 (TP70P)
Bit15-10
Bit9-8
Bit7-6
Bit5-4
Bit3-2
Bit1-0
N/A
DA2
N/A
N/A
AD1
AD0
Value
AD mode
DA mode
00 0mA~20mA 0mA~20mA
01 4mA~20mA 4mA~20mA
Note: the temperature input channel only supports Pt100. No setup is needed.
