Classification API
Mnemonic
PULSE
Function
16 bits
32 bits
63
INCD
–
–
Incremental drum sequencer
64
TTMR
–
–
Teaching timer
65
STMR
–
–
Special timer
66
ALT
–

Alternate state
67
RAMP
–
–
Ramp variable value
69
SORT
–
–
Data sort
Serial I/O
80
RS
–
–
Serial communication
82
ASCI
–

Convert HEX to ASCII
83
HEX
–

Convert ASCII to HEX
87
ABS
DABS

Absolute value
88
PID
DPID
–
PID control
Basic
Instructions
89
PLS
–
–
Rising-edge output
90
LDP
–
–
Rising–edge detection operation
91
LDF
–
–
Falling–edge detection operation
92
ANDP
–
–
Rising-edge series connection
93
ANDF
–
–
Falling-edge series connection
94
ORP
–
–
Rising-edge parallel connection
95
ORF
–
–
Falling-edge parallel connection
96
TMR
–
–
Timer
97
CNT
DCNT
–
Counter
98
INV
–
–
Inverse operation
99
PLF
–
–
Falling-edge output
Communication
Instructions
100
MODRD
–
–
Read Modbus data
101
MODWR
–
–
Write Modbus Data
102
FWD
–
–
Forward Operation of VFD
103
REV
–
–
Reverse Operation of VFD
Communication
Instructions
104
STOP
–
–
Stop VFD
105
RDST
–
–
Read VFD Status
106
RSTEF
–
–
Reset Abnormal VFD
107
LRC
–

LRC checksum
108 CRC – 
CRC checksum
150
MODRW
–
–
MODBUS Read/ Write
206
ASDRW
–
–
ASDA servo drive R/W
Floating Point
Operation
110
– DECMP 
Floating point compare
111
–
DEZCP

Floating point zone compare
112
–
DMOVR

Move floating point data
116
–
DRAD

Degree

Radian
117
–
DDEG

Radian  Degree
118
– DEBCD 
Float to scientific conversion
119
–
DEBIN

Scientific to float conversion
120
–
DEADD

Floating point addition
121
–
DESUB

Floating point subtraction
122
–
DEMUL

Floating point multiplication
