English-4
Accessories (NC200A-LI-A_; NC200P-LI-A_)
Accessory
NC200A-LI-A_ NC200P-LI-A_
Purpose
One 3-pin connector
● ●
For 24 V
DC
power
One terminal resistor
● ●
For DMCNET
Eight sets of M3 screws and
nuts
● ●
For securing to the machine
One female 15-pin connector
with one fitting
● For SPINDLE
One male and one female
15-pin connectors
with two sets of fitting
●
For MPG and SPINDLE
One 2-pin connector
●*
1
●*
2
For the 24 V
DC
power to the
secondary panel
One 8-pin connector ● ●
For the X output contact of the
secondary panel
One 5-pin connector
● ●
For the X output contact of the
secondary panel
One 2-pin connector
●
For IES of the secondary panel
IES: Internal emergency stop
One 6-pin connector ● ●
For HSI
HSI: For HSI (high-speed G31)
and external emergency stop
One 6-pin connector ● ●
For REMOTE I/O
REMOTE I/O: High-speed
serial I/O
Note:
1. On NC200A-LI-A, this connector is for the I/O of the secondary panel.
2. On NC200P-LI-A, this connector is for the cycle start, feed hold, and emergency stop button and I/O of the
secondary panel.
Ambient Conditions of Storage
Before installation, this product has to be kept in the shipping carton. If the product is
temporarily not in use, please comply with the following instructions in order to retain the
warranty coverage as well as for future maintenance:
The product should be stored in dry and dust-free place. It is preferable to pack the
product properly and store it on shelf or table.
Store the product within an ambient temperature range of -20 to 60°C (℃ -4°F to
140°F).
Store the product within a relative humidity range of 10% to 95%, non-condensing.
Avoid storing the product in the environment containing corrosive gas and liquid.
Avoid storing the product in the environment with vibration that is out of the range
stipulated in the specification.
