3.2.1 LCD Display and Buttons
3.2.2 Inverter Input/Output Interface
Figure 3-3: LCD display and buttons
Figure 3-4: Input/output interface
Dry
contact
AC
connector
DC
connector
Communication
RS-485
DC switch
The DC switch is only presented in the -120 models. Model series -020 does
not have the DC switch.
NOTE
13
