• The bracket supplied with the unit is specially designed and should be
the only mounting device used for the unit.
• It is recommended to install the inverter in a suitable location which
offers easy and safe access for service and maintenance.
• Please leave an appropriate gap in between units when installing multiple
solar inverter systems.
• Please install solar inverter at eye level to allow easy observation for
operation and parameter setting.
• Ambient temperature for operation: -25°C~+60°C (power derating above
40°C).
CAUTION !
Please ensure the spacing requirement to allow for sufficient convective cooling.
It is essential to ensure sufficient space for product operation as shown in Figure 4-3.
Figure 4-3: Adequate installation gap
16
Installation
>50cm
>50cm
>30cm>30cm >30cm
