Delta RPI M6A

27
Installation guide for solar inverters RPI M6A M8A M10A EU V5 EN 2022-08-15
General specications RPI M6A RPI M8A RPI M10A
Delta model name RPI M6A RPI M8A RPI M10A
Delta part number RPI602FA0E1000 RPI802FA0E1000 RPI103FA0E1000
Maximum e󰀩ciency 98.3% 98.3% 98.3%
E󰀩ciency EU 97.6% 97.9% 98.0%
Operating temperature range -25 ... +60 °C
Operating temperature range without dera-
ting
-25 ... +40 °C
Storage temperature range -25 ... +60 °C
Relative humidity 0 to 100%, non-condensing
Max. geographical operating height
2000 m above sea level
Standards and guidelines RPI M6A RPI M8A RPI M10A
Protection class IP65
Safety class I
Level of pollution II
Overload behavior Current limit, power limit
Safety IEC 62109-1/-2, CE-compliance
EMC EN 61000-6-2, EN 61000-6-3
Noise immunity IEC 61000-4-2/-3/-4/-5/-6/-8
Distortion factor EN 61000-3-2 EN 61000-3-12
Fluctuations and brillations EN 61000-3-3 EN 61000-3-11
Grid interfaces see solarsolutions.delta-emea.com
1)
When operating with symmetric DC inputs (50%/50%)
2)
IEC 60664-1, IEC 62109-1
3)
The maximum AC apparent power species the maximum power that an inverter is able to supply. This maximum apparent power is not necessarily
achieved.
4)
Limited to 4.99 kVA, when grid type AU/NZ PL 4.99k is selected.
5)
AC voltage and frequency range are programmed using the corresponding country specications.
Technical Data
