26
Installation guide for solar inverters RPI M6A M8A M10A EU V5 EN 2022-08-15
Input (DC) RPI M6A RPI M8A RPI M10A
Recommended maximum PV power
1)
7500 W
P
10000 W
P
12500 W
P
Maximum power 6600 W 8800 W 11,000 W
Input voltage range 200 ... 1000 V
DC
Max. input voltage 1000 V
DC
Rated voltage 600 V
DC
Switch-on voltage >250 V
DC
Switch-on power 40 W
MPP operating voltage range 200 ... 1000 V
DC
MPP operating voltage range at full power
Symmetrical load
315 to 800 V
DC
415 to 800 V
DC
415 to 800 V
DC
Asymmetrical load (60/40%) 425 to 800 V
DC
565 to 800 V
DC
415 to 800 V
DC
Maximum input current, total (DC1/DC2) 20 A (10 A/10 A) 20 A (10 A/10 A) 25 A (15 A/10 A)
Maximum short-circuit current in the event
of failure
13 A/13 A 13 A/13 A 19.5 A/13 A
Number of MPP trackers Parallel inputs: 1 MPP tracker, separate inputs: 2 MPP trackers
Maximum asymmetry 60%/40%
Number of DC inputs, total (DC1/DC2) 2 (1/1) 2 (1/1) 3 (2/1)
Galvanic isolation No
Overvoltage category
2)
II
Output (AC) RPI M6A RPI M8A RPI M10A
Maximum apparent power
3)
6300 VA 8400 VA 10500 VA
Rated apparent power 6000 VA
4)
8000 VA 10000 VA
Voltage range
5)
230 ± 20% /400 V
AC
± 20%, 3 phases + protective ground conductor(PE) or
3 phases + N + protective ground conductor (PE)
Nominal current 8.7 A 11.6 A 14.5 A
Maximum current 9.7 A 13 A 16 A
Switch-on current 31 A/100 µs
Rated frequency 50/60 Hz
Frequency range
5)
50 ± 5 Hz / 60 ± 5 Hz
Power factor adjustment range 0.8 cap ... 0.8 ind
Total harmonic distortion (THD) < 3% at rated apparent power
DC power supply < 0.5% at rated current
Power loss in night mode
< 2 W
Overvoltage category
2)
III
Mechanical details RPI M6A RPI M8A RPI M10A
Dimensions (W x H x D)
510 x 445 x 177 mm
Weight 25 kg 25 kg 26 Kg
Cooling Natural convection
AC connection type Amphenol C16-3
DC connection type Multi-contact MC4
Communication interfaces 2 x RS485, 1 x dry contact, 1 x EPO (E-Power o), 6 x digital inputs
Technical Data
