Delta TP04G-AL2 User Manual

- 3 -
Model
Spec.
TP04G-AL TP04G-AL2
China: (GB2324-80 codes) Simplified Chinese fonts
Resolution 192 × 64 dots
Display range 101.8mm(W) × 35.24mm(H); 4.1” (diagonal preferred)
Font size ASCII: 5×8, 8×8, 8×12, 8×16
Display text
5×8 dots 38 characters × 8 rows
8×8 dots 24 characters × 8 rows
8×12 dots 24 characters × 5 rows
8×16 dots 24 characters × 4 rows
Serial
communication port
RS-232(COM1)
Asynchronous transmission method: RS-232
Data length: 7 or 8 bits, Stop bits: 1 or 2 bits, Parity: None/Odd/Even
Baud rate: 9,600bps~115,200bps
RS-232: 9 PIN D-SUB male
Extension
communication port
RS-422(COM2)
RS-485(COM2)
Not supported
Asynchronous transmission
method: RS-485 / RS-422
Data length: 7 or 8 bits
Stop bits: 1 or 2 bits
Parity: None/Odd/Even
Baud rate: 9,600bps ~ 115,200bps
RS-422: 9 PIN D-SUB male
RS-485: 6 PIN removable terminal
Battery cover DC 3V battery
Extension interface The slot for program copy card
6 PIN removable
terminal
Not supported (3 PIN fixed
terminal, DC 24V input)
Include DC 24V input and RS-485
communication input
Panel component Explanation
Alarm LED
indicator (RED)
Status 1: When power is ON, LED will start to blink slowly
Status 2: When the user-defined conditions are met, LED will blink for one
second repeatedly along with an alarm sound.
Power LED
indicator (Green)
When the power is connected to the product, LED will be ON.
Display area LCM display area. It is used to display current program status.
Function
keys
←
Users can re-define its function through operation in user interface.
F1
It can be a left direction key (move the cursor to the left) in value input
mode. Users can re-define its function through operation in user interface.
F2
It can be a left direction key (move the cursor to the left) in value input
mode. Users can re-define its function through operation in user interface.
F3
It can be a selection key to set the value in value input mode. Users can
re-define its function through operation in user interface.
F4
It can be a right direction key (move the cursor to the right) in value input
mode. Users can re-define its function through operation in user interface.
F5
It can be a right direction key (move the cursor to the right) in value input
mode. Users can re-define its function through operation in user interface.
Up/Down keys
Up: It is used to increase the value or move up one page.
Down: It is used to decrease the value or move down one page.
Users can re-define its function through operation in user interface.
Enter key It is used to input a value or accept a programming command.
 Electrical Specifications
Model
Spec.
TP04G-AL TP04G-AL2
CPU STM32F101
Program memory 256KB flash memory
