Delta TP04G-AL2 User Manual

- 2 -
Figure3
163.6 [6.441]
37
[1.457]
1
0
8
.
6
[
4
.
2
7
6
]
9
5
[
3
.
7
4
]
 Mounting Dimensions (Panel Cutout)
(Units: mm, [ ]: inch)
 Top View (Units: mm, [ ]: inch)
Figure4
150.5~152 [5.9252~5.9842]
Thickness Range 0.5~5mm
9
5
.
5
~
9
7
.
0
[
]
3
.
7
5
9
8
~
3
.
8
1
8
8
Figure5
150 [5.905]
2
9
.5
[1
.1
6
1
]
7
.
5
[
0
.
2
9
5
]
 Model Name and Serial Number
TP04G
- -
Graphic mode
Blank: including CE and UL
C: CE only
Blank: RS-232 interface only
Series name
Key spec.
Model type
Safety approval
Communication interface
2: RS-232 / RS-485 / RS-422
interface
A
L
 Function Specifications
Model
Spec.
TP04G-AL TP04G-AL2
Screen type / Display
color
STN-LCD / Monochromatic
Driver
Only for Delta automation
products
For automation products of Delta
and other manufacturers
Function / Numeric
keys
F1~F5, ESC, ←, Enter and Up/Down Keys
Alarm LED indicator
(RED)
Power on indication (Blink for three times)
Communication error alarm
Special indication by user programming
Backlight
The automatic turn-off time of backlight: 1 ~ 99 minutes (0 = do not
turn off) (Life span of backlight is about 50,000 hours at 25°C)
Contrast adjustment Set by software, 10 levels of adjustment
Model
Spec.
TP04G-AL TP04G-AL2
Language / Font
ASCII: (Code page 850) Alphanumeric (including European char.)
Taiwan: (Big 5 codes) Traditional Chinese fonts
