Delta VFD-A Series User Manual

82
Fuse Specification Chart
Smaller fuses than those shown in the table are permitted.
Line Fuse
Model
Input
Current (A)
Output
Current (A)
I (A) Bussmann P/N
VFD007A21A 11 5.0
40 JJN-40
VFD007A23A 7.4 5.0
20 JJN-20
VFD007A43A 4.2 3.0
10 JJS-10
VFD015A21A 15 6.5
60 JJN-60
VFD015A23A 9.9 6.5
25 JJN-25
VFD015A43A 6 4.2
15 JJS-15
VFD015A43B 5.8 4.2
15 JJS-15
VFD022A21A 27 11
100 JJN-100
VFD022A23A 15.5 11
40 JJN-40
VFD022A43A 7.2 5.5
20 JJS-20
VFD037A23A 19.6 17
60 JJN-60
VFD037A43A 8.5 8.2
30 JJS-30
VFD055A23B 33.5 25
100 JJN-100
VFD055A43B 14 13
50 JJS-50
VFD075A23B 43.3 33
125 JJN-125
VFD075A43B 20.6 18
70 JJS-70
VFD110A23A 46 46
175 JJN-175
VFD110A43A 28 24
90 JJS-90
VFD150A23A 76 60
225 JJN-225
VFD150A43A 30 32
125 JJS-125
VFD185A23A 83 75
300 JJN-300
VFD185A43A 39 38
150 JJS-150
VFD220A23A 99 87
340 JJN-300
VFD220A43A 49 45
175 JJS-175
