Delta VFD-L User Manual

9
Parameters (saved in the EEPROM) : the parameter can be set during the operation.
Parameter Parameter Function Parameter Setting
Factory
Setting
Customer Setting
0 Identity code of Drive Depend on drive Read only
1 Rating current Depend on drive 1 Read/Write
2 Parameter Reset 10: Reset 0 Read/Write
3 Max. Operation Freq.
0: 50 Hz
1: 60 Hz
2: 100 Hz
3: 120 Hz
1 Read Only
4
Accel/Decel Time 0.05 to 30.00 sec 5.00 Read/Write
5 Reverse Inhibit
0: Reverse
disable
1: Reverse
enable
1 Read/Write
6 Torque Increase
0: High Torque
1: Low Torque
1 Read/Write
7 Electronic Thermal
0: 25/60 w
1: 40/100 w
1 Read/Write
8 Communication Addresses 01 to 63 1 Read/Write
9 Software Version Read only #.# Read Only
Address List:
The contents of available addresses are shown as below:
Content: Address: Function:
AC drive
Parameters
nnnnH
nnnn means parameter number, for example, the address of 0004 is
0004H. When reading parameter by command code 03H, only one
parameter can be read at one time.
Bit 0 to 1
00B: No function
01B: Stop
10B: Run
11B: No function
Bit 2 to 3 Reserved
Bit 4 to 5
00B: No function
01B: FWD
10B: REV
11B: Change direction
2000H
Bit 6 to 15 Reversed
2001H Frequency command
Bit 0 1: Reversed
Bit 1 1: Reset
Command
Write only
2002H
Bit 2-15 Reserved

Delta VFD-L Specifications

General

Series	VFD-L
Control Method	V/F Control
Enclosure Rating	IP20
Type	AC Motor Drive
Output Frequency	1.0 ~ 400 Hz
Overload Capacity	150% for 60 seconds
Protection	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Braking Unit	Built-in
Communication	RS-485 (Modbus ASCII/RTU)
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C ~ 60°C
Humidity	90% RH or less (non-condensing)
Altitude	Up to 1000m without derating
Cooling Method	Fan Cooled
Input Voltage	Single-phase 200-240V
