Appendix B  Accessories_VFD-B Series
Revision 10/2005, BE13, SW V4.08    B-35
B.7 Zero Phase Reactor (RF220X00A)
Dimensions are in millimeter and (inch)

Motor
HP  kW
Qty.
Recommended
Wire Size
(mm
2
)
Wiring
Method
1/4  0.2
1/2  0.5
1  0.75
2  1.5
0.5 - 5.5
3   2.2  3.5 - 5.5
5   3.7
1
5.5
Diagram
A
7.5  5.5
10  7.5
8
15  11  22
20  15
25  18.5
30
30  22  38
40  30
230 V Series
50  37
4
38 - 100
Diagram
B
1/4  0.2
1/2  0.5
1  0.75
2  1.5
3   2.2
5   3.7
0.5 - 5.5
7.5  5.5  3.5 - 5.5
10  7.5
1
5.5
Diagram
A
15  11
20  15
8 - 14
25  18.5  14
30  22
40  30
22
50  37  30
60  45  50
75  55
460 V Series/575V series
100  75
4
38 - 100
Diagram
B




Power
Supply
Zero Phase Reactor
MOTOR
U/T1
V/T2
W/T3
R/L1
S/L2
T/L3


U/T1
V/T2
W/T3
R/L1
S/L2
T/L3
Power
Supply
Zero Phase Reactor
MOTOR


Diagram B
Please  put  all  wires  through  4  cores  in  series
without winding.

Diagram A
Please wind each wire 4 times around the
core. The reactor must be put at inverter
output as close as possible.
