Appendix B Accessories_VFD-B Series
Revision 10/2005, BE13, SW V4.08 B-39
B.10 Fuse Specification Chart
Smaller fuses than those shown in the table are permitted.
Line Fuse
Model
I (A)
Input
I (A)
Output
I (A) Bussmann P/N
VFD007B21A 11.9 5.0 20 JJN-20
VFD007B23A 5.7 5.0 10 JJN-10
VFD007B43A 3.2 2.7 5 JJS-5
VFD007B53A
2.0 1.7 5 JJS-6
VFD015B21A/B 15.3 7.0 30 JJN-30
VFD015B23A/B 7.6 7.0 15 JJN-15
VFD015B43A 4.3 4.2 10 JJS-10
VFD015B53A
3.6 3.5 5 JJS-6
VFD022B21A 22.0 11 50 JJN-50
VFD022B23A 15.5 11 30 JJN-30
VFD022B43B 5.9 5.5 15 JJS-15
VFD022B53A
4.9 4.5 10 JJS-10
VFD037B23A 20.6 17 40 JJN-40
VFD037B43A 11.2 8.5 20 JJS-20
VFD037B53A
9.9 7.5 20 JJS-20
VFD055B23A 26 25 50 JJN-50
VFD055B43A 14 13 30 JJS-30
VFD055B53A
10.8 10 20 JJS-20
VFD075B23A 34 33 60 JJN-60
VFD075B43A 19 18 40 JJS-40
VFD075B53A
14.3 13.5 30 JJS-30
VFD110B23A 50 49 100 JJN-100
VFD110B43A 25 24 50 JJS-50
VFD110B53A
19.8 19 40 JJS-40
VFD150B23A 60 65 125 JJN-125
VFD150B43A 32 32 60 JJS-60
VFD150B53A
22 22 40 JJS-40
VFD185B23A 75 75 150 JJN-150
VFD185B43A 39 38 75 JJS-70
VFD185B53A
27.7 27 50 JJS-50
