Chapter 2 Installation and Wiring
_
VFD-B Series
Revision 10/2005,
BE13, SW V4.08
2-33
75-100 HP (55-75kW) 460V
VFD550B43A, VFD750B43A
T/
L3
S
/L2
R/
L1
POW
ER
+1
V
/T2
U
/T1
+2
20
0kgf-cm
(17
3in-lb
f)
Screw Torque:
IM
3
W
/T3
MOTOR
Control T
erminal
T
orque: 4Kgf-cm (3 in-lbf)
Wire: 12-24
A
WG (3.3-0.2 mm
2
)
Power T
erminal
T
orque: 200 kgf-cm (173 in-lbf)
Wire:
VFD550B43A
: 2/0
A
WG (67.4 mm
2
)
VFD750B43A: 3/0
A
WG (85 mm
2
)
Wire T
ype: S
tranded copper only
, 75
q
C
50
52
