Chapter 11 Summary of Parameter SettingsME300
11-3
Pr. Explanation Settings Default
26: GFF ground fault (G.) (unit: %)
27: DC BUS voltage ripple (r.) (unit:
V
DC
)
30: Output user-defined parameter (U)
31: H page x 00-05 user gain (K)
35: Control mode: 0 = Speed control mode (SPD)
36: Current operating carrier frequency (J.) (Unit: Hz)
38: Drive status (6.)
41: KWH (J) (unit: kWh)
42: PID target value (h.) (unit: %)
43: PID offset (o.) (unit: %)
44: PID output frequency (b.) (unit: Hz)
47: Master frequency value (A) (unit: Hz)
60: Display PID setting and feedback signal
61: Display the content of the running program ( 1=tt )

00-05
Coefficient gain in actual
output frequency
0.00–160.00 1.00
00-06 Firmware version Read only #.#

00-07
Parameter protection
password input
0–65535
0–3 (the number of password attempts allowed)
0

00-08
Parameter protection
password setting
0–65535
0: No password protection / password entered incorrectly
(Pr.00-07)
1: Password set
0
00-10 Control mode 0: Speed mode 0
00-11 Speed Control mode
0: VF (IM V/F control)
2: SVC (Pr.05-33 set as IM or PM)
0
00-16 Load selection
0: Normal load
1: Heavy load
1
00-17 Carrier frequency
Normal load: 2–15 kHz
Heavy load: 2–15 kHz
4
4

00-20
Master frequency
command (AUTO) source
0: Digital keypad
1: RS-485 communication
2: External analog input (refer to Pr.03-00)
3: External UP/DOWN terminal
4: Pulse input without direction command (refer to
Pr.10-16 without direction)
7: Digital keypad dial
0

00-21
Operation command
(AUTO) source
0: Digital keypad
1: External terminals
2: RS-485 communication input
0
