Chapter 7 Optional AccessoriesCP2000
7-2
Table 7-1
The optional accessories listed in this chapter are available upon request. Installing additional
accessories to your drive would substantially improve the drive’s performance. Please select an
applicable accessory according to your need or contact the local distributor for suggestion.
7-1 Brake Resistors and Brake Units Used in AC Motor Drives
230V Model
Applicable
Motor
125% Braking Torque 10%ED *
1
Max. Brake Torque *
2
HP kW
Braking
Torque
[kg-m]
Brake
Unit
Braking Resistor series for
each Brake Unit *
4
Resistor value
spec. for each
AC motor Drive
Total
Braking
Current [A]
Min.
Resistor
Value [Ω]
Max. Total
Braking
Current [A]
Peak
Power
[kW]
VFDB *
3
P/N Q’ty Usage
1 0.7 0.5 - BR080W200 1 - 80W 200Ω 1.9 63.3 6 2.3
2 1.5 0.5 - BR080W200 1 - 80W 200Ω 1.9 63.3 6 2.3
3 2.2 1.0 - BR200W091 1 - 200W 91Ω 4.2 47.5 8 3.0
5 3.7 1.5 - BR300W070 1 - 300W 70Ω 5.4 38.0 10 3.8
7.5 5.5 2.5 - BR400W040 1 - 400W 40Ω 9.5 19.0 20 7.6
10 7.5 3.7 - BR1K0W020 1 - 1000W 20Ω 19 14.6 26 9.9
15 11 5.1 - BR1K0W020 1 - 1000W 20Ω 19 14.6 26 9.9
20 15 7.4 - BR1K5W013 1 - 1500W 13Ω 29 12.6 29 11.0
25 18 10.2 - BR1K0W4P3 2 2 series 2000W 8.6Ω 44 8.3 46 17.5
30 22 12.2 - BR1K0W4P3 2 2 series 2000W 8.6Ω 44 8.3 46 17.5
40 30 14.9 - BR1K5W3P3 2 2 series 3000W 6.6Ω 58 5.8 66 25.1
50 37 20.3 2015*2 BR1K0W5P1 2 2 series 4000W 5.1Ω 75 4.8 80 30.4
60 45 25 2022*2 BR1K2W3P9 2 2 series 4800W 3.9Ω 97 3.2 120 45.6
75 55 30.5 2022*2 BR1K5W3P3 2 2 series 6000W 3.3Ω 118 3.2 120 45.6
100 75 37.2 2022*3 BR1K2W3P9 2 2 series 7200W 2.6Ω 145 2.1 180 68.4
125 90 50.8 2022*4 BR1K2W3P9 2 2 series 9600W 2Ω 190 1.6 240 91.2
460V Model
Applicable
Motor
125%Braking Torque 10%ED *
1
Max. Brake Torque *
2
HP kW
Braking
Torque
[kg-m]
Brake
Unit
Braking Resistor series for each
Brake Unit *
4
Resistor value
spec. for each
AC motor Drive
Total
Braking
Current [A]
Min.
Resistor
Value [Ω]
Max. Total
Braking
Current [A]
Peak
Power
[kW]
VFDB *
3
P/N Q’ty
Usage
1 0.7 0.5 - BR080W750
1 - 80W 750Ω 1 190.0 4 3.0
2 1.5 0.5 - BR080W750
1 - 80W 750Ω 1 190.0 4 3.0
3 2.2 1.0 - BR200W360
1 - 200W 360Ω 2.1 126.7 6 4.6
5 3.7 1.5 -
BR300W250 1 - 300W 250Ω 3 108.6 7 5.3
5.5 4.0 2.5 - BR400W150
1 - 400W 150Ω 5.1 84.4 9 6.8
7.5 5.5 2.7 - BR1K0W075
1 - 1000W 75Ω 10.2 54.3 14 10.6
10 7.5 3.7 -
BR1K0W075 1 - 1000W 75Ω 10.2 54.3 14 10.6
15 11 5.1 - BR1K0W075
1 - 1000W 75Ω 10.2 47.5 16 12.2
20 15 7.4 -
BR1K5W043 1 - 1500W 43Ω 17.6 42.2 18 13.7
25 18 10.2 -
BR1K0W016 2
2 series
2000W 32Ω 24 26.2 29 22.0
30 22 12.2 -
BR1K0W016 2
2 series
2000W 32Ω 24 23.0 33 25.1
40 30 14.9 -
BR1K5W013 2
2 series
3000W 26Ω 29 23.0 33 25.1
50 37 20.3
-
BR1K0W016 4
2 parallel,
2 series
4000W 16Ω 47.5 14.1 54 41.0
60 45 25
4045*1
BR1K2W015 4
2 parallel,
2 series
4800W 15Ω 50 12.7 60 45.6
75 55 30.5
4045*1
BR1K5W013 4
2 parallel,
2 series
6000W 13Ω 59 12.7 60 45.6
100 75
37.2
4030*2
BR1K0W5P1 4
4 series
8000W 10.2Ω 76 9.5 80 60.8
125 90 50.8
4045*2
BR1K2W015 4
2 parallel,
2 series
9600W 7.5Ω 100 6.3 120 91.2
150 110 60.9
4045*2
BR1K5W013 4
2 parallel,
2 series
12000W 6.5Ω 117 6.3 120 91.2
175 132 74.5
4110*1
BR1K2W015 10
5 parallel,
2 series
12000W 6Ω 126 6.0 126 95.8
215 160 89.4
4160*1
BR1K5W012 12
6 parallel,
2 series
18000W 4Ω 190 4.0 190 144.4
