Chapter 11 Summary of Parameter SettingsCP2000
11-12
02 Digital Input / Output Parameters
Pr. Parameter Name Setting Range Default
02-00
Two-wire / Three-wire operation
control
0: Two-wire mode 1, power on for operation control
1: Two -wire mode 2, power on for operation
control
2: Three-wire, power on for operation control
0
02-01 Multi-function input command 1 (MI1) 0: No function 1
02-02 Multi-function input command 2 (MI2) 1: Multi-step speed command 1 2
02-03 Multi-function input command 3 (MI3) 2: Multi-step speed command 2 3
02-04 Multi-function input command 4 (MI4) 3: Multi-step speed command 3 4
02-05 Multi-function input command 5 (MI5) 4: Multi-step speed command 4 0
02-06 Multi-function input command 6 (MI6) 5: Reset 0
02-07 Multi-function input command 7 (MI7) 6: JOG command (By KPC-CC01 or external 0
02-08 Multi-function input command 8 (MI8) control) 0
02-26
Input terminal of I/O extension card
(MI10)
7: Acceleration / deceleration speed inhibit
8: 1
st
, 2
nd
acceleration / deceleration time selection
0
02-27
Input terminal of I/O extension card
(MI11)
9: 3
rd
, 4
th
acceleration / deceleration time selection
10: EF input (Pr.07-20)
0
02-28
Input terminal of I/O extension card
(MI12)
11: Base Block (B.B) input from external
12: Output stop
0
02-29
Input terminal of I/O extension card
(MI13)
13: Cancel the setting of auto-acceleration /
auto-deceleration time
0
02-30
Input terminal of I/O extension card
(MI14)
14: Switch between motor 1 and motor 2
15: Rotating speed command from AVI1
0
02-31
Input terminal of I/O extension card
(MI15)
16: Rotating speed command from ACI
17: Rotating speed command from AVI2
0
18: Forced to stop (Pr.07-20)
19: Digital up command
20: Digital down command
21: PID function disabled
22: Clear the counter
23: Input the counter value (MI6)
24: FWD JOG command
25: REV JOG command
28: Emergency stop (EF1)
29: Signal confirmation for Y-connection
30: Signal confirmation for ᇞ-connection
38: Disable write EEPROM function
40: Force coasting to stop
41: HAND switch
42: AUTO switch
49: Enable drive
50: Slave dEb action to execute
51: Selection for PLC mode bit0
52: Selection for PLC mode bit1
53: Trigger CANopen quick stop
54: UVW output electromagnetic valve switch
To Next Page
