Electrical Specification
Power supply voltage 5 V
DC
(supplied by AC motor drive)
Insulation voltage 500 V
DC
Communication wire
power consumption
0.85 W
Power consumption
1 W
Weight 23 g
Environment
Noise immunity
ESD (IEC 61800-5-1,IEC 61000-4-2)
EFT (IEC 61800-5-1,IEC 61000-4-4)
Surge Test (IEC 61800-5-1,IEC 61000-4-5)
Conducted Susceptibility Test (IEC 61800-5-1,IEC 61000-4-6)
Operation /storage
Operation: -10ºC–50ºC (temperature), 90% (humidity)
Storage: -25ºC–70ºC (temperature), 95% (humidity)
Shock / vibration
resistance
International standards: IEC 61800-5-1, IEC 60068-2-6 / IEC 61800-5-1, IEC
60068-2-27
8-8-4 Installation
DeviceNet Connector
PIN Signal Color Definition
5
4
3
2
1
1 V+ Red DC24V
2 H White Signal+
3 S - Earth
4 L Blue Signal-
5 V- Black 0V
8-8-5 LED Indicator & Troubleshooting
There are 3 LED indicators on CMC-DN01: POWER LED, MS LED and NS LED. POWER LED
displays the status of power supply. MS LED and NS LED are dual-color LED, displaying the
connection status of the communication and error messages.
POWER LED
LED status Indication How to correct it?
OFF Power supply in abnormal status.
Check the power supply of CMC-DN01.
Green light ON Power supply in normal status --
